Price
US $80000-100000
Model
FDSL2000
MOQ
1 set

Item specifics

Refrigerant
Freon
Structure
Assembled
Suitable for
Factory
Refrigeration System
Brand Compressor Unit
Size
Customized
Use Nature
Production
Usage
Food
Freezer Body Material
304 Stainless Steel
Specification
CE ISO9001
Transport Package
Seaworthy Plywood Case

Review

Description

                             China high cost-effective spiral freezer 1000kg/h-6000kg/h
FDSL spiral freezer drawing
Double Spiral Freezer suitable for the capacity over 1000kg/h , the operation of low input and low output of products is convenient and easier to realize automation.
suitable for rapid freezing of large products.
at same time can be used as spiral cooler
the  belt width 600mm 710mm 800mm can choose
with stainless  steel
the panels adopt  150mm thickness  double face Stainless  steel insulation .
whole spiral freezer structure adopt  full stainless  steel.
can according to clients requirements  to customize .

Spiral Freezer, a state-of-the-art freezing machine designed to meet your production needs. With its fully automated production system, this freezer is capable of freezing a wide range of food items including pastries, meat, seafood, and ice cream.

Featuring a production capacity ranging from 300kg/h to 10T/H, our Spiral Freezer is available in two variations: single spiral or double spiral. This versatility allows for efficient freezing or cooling processes, depending on your specific requirements.

Customization is also a key aspect of our Spiral Freezer. We understand that each customer has unique needs, and therefore we offer the option to tailor the machine to your exact specifications.

Invest in our Spiral Freezer today and experience the benefits of automated freezing, increased productivity, and the ability to meet diverse freezing and cooling demands. Trust in our professional-grade equipment for your freezing needs.


FDSL series

Capacity

Install power

Refrigerant Cooling

Room size

Belt width

FDSL1000

1000KG/H

 22.9KW

170KW (±40℃)

10*7*2.5m

 600mm

FDSL1500

1500KG/H

31.9KW

240KW (±40℃)

10*7*3m

 600mm

FDSL2000

2000KG/H

45.6KW

320KW (±40℃)

10*7*3.5m

 600mm

FDSL3000

3000KG/H

58.8KW

480KW (±40℃)

10*7*4m

 600mm
