High-Quality ODM Impingement Tunnel Freezer for Seafood Factories and Frozen Food Processing
High-Quality ODM Impingement Tunnel Freezer for Seafood Factories and Frozen Food Processing
High-Quality ODM Impingement Tunnel Freezer for Seafood Factories and Frozen Food Processing
High-Quality ODM Impingement Tunnel Freezer for Seafood Factories and Frozen Food Processing
High-Quality ODM Impingement Tunnel Freezer for Seafood Factories and Frozen Food Processing
High-Quality ODM Impingement Tunnel Freezer for Seafood Factories and Frozen Food Processing
Price
US $18000-20000
Model
Impingement tunnel freezer
MOQ
1 set

Item specifics

Use For
fish
Origin
China
Loading capacity
1000kg
Effective Belt Width
2000mm
Cold Consumption
170KW
Dimension(L*W*H)
12*4.2*3M
Type
Impingement freezer
Voltage
440V 60HZ
After-sales service
12months after commercial running
Refrigerant
R507/ R404A/R717

Review

Description

Impingement Tunnel Freezer Product Description

Industrial Impingement Tunnel Freezer, perfect freezing effect, suitable for various food; High efficiency, meets food standard.

It's mostly used for flour food freezing, fruit and vegetable freezing, meat freezing, seafood freezing and prepared food freezing.

 In quick strip, cubic or grain food, such as shrimp meat, shrimp, sliced fish, meat dumpling, chicken.

It saves energy and is convenient in cleaning and maintenance.

Impact belt individual quick freezer is a kind of high efficient continuous freezer,it is the new generation of product who has higher economic benefits and the food it frozen has the better quality and aesthetic appearance.



Impact tunnel freezer

FIW1000 Impingement FREEZER TECHNICAL PARAMETERS


Product

Frozen fish

Capacity

1000kg/h

In/Out Temp.

+15 to -18

Freezer Temp.

-38

In/Out Time

10-50min

Refrigerant

R717

Consumption

170kw

Freezing Container Thickness

150mm

Product Height

≤100mm

Belt Width

2000mm

Product Input Conveyor/Output Conveyor

750 mm

Water Input Pressure

3 kg/cm2

Freezer Power

35.2KW

Freezer SizeL*W*H

12000×4200×3000mm

Freezer Body Material

Duplex stainless steel polyurethane insulation board density or 40 kg/m3, the thickness of 150 mm, 304 stainless steel outer plate thickness more than 0.8 mm

Main Electric Brand

Schneider(France)

Belt and Speed

Food-grade stainless steel mesh belt; Frequency conversion stepless speed regulation

Slide Track Material

Ultrahigh molecular polyethylene material.

Internal Structure

All made of 304 Stainless Steel Material, Argon arc welding

Evaporator

Effective from large aluminum finned tube set, stainless steel panel stent

Fan and Motor

Aluminum alloy stainless steel duct fan low noise and waterproof electric power consumption
